30" Straight Bar Sheet Pile Protector

  • Model: X-09800

The 30" cast steel straight bar is designed to be cut into appropriate lengths to cover the sheet pile web and flanges. The protector will reinforce the end of the pile for optimum penetration into any soil but is especially beneficial when obstructions are anticipated. It also opens a slightly larger hole to speed installation and preserve coatings. Used for sheet pile web and/or flanges with thickness of ½" or less. Some sheet pile sections may require a combination of both the 30" X09800 and the 28" X09828 to cover the web and flanges. APF can assist with requirements for your particular sheet pile.

Size: Custom sizes available upon request.
Benefits: Value of the protectors has been proven by piles pulled for reuse after being driven. They attach with a minimum of weld and protect the pile ends to prevent tearing and buckling of piles.
Steel Grade: High Strength Heat-Treated Cast Steel Grade ASTM A148 90/60.

Download Data Sheet

28" Straight Bar Sheet Pile Protector

  • Model: X09828

The 28" cast steel straight bar is designed to be cut into appropriate lengths to cover the sheet pile web and flanges. The protector will reinforce the end of the pile for optimum penetration into any soil but is especially beneficial when obstructions are anticipated. It also opens a slightly larger hole to speed installation and preserve coatings. Used for sheet pile web and/or flanges with thickness greater than ½". Some sheet pile sections may require a combination of both the 28" Model X09828 and 30" Model X09800 to cover the web and flanges. APF can assist with requirements for your particular sheet pile.

Size: Custom sizes available upon request.
Benefits: Value of the protectors has been proven by piles pulled for reuse after being driven. They attach with a minimum of weld and protect the pile ends to prevent tearing and buckling of piles.
Steel Grade: High Strength Heat-Treated Cast Steel Grade ASTM A148 90/60.

Download Datasheet

One Piece Sheet Pile Protector

  • Models: X9-PZ40 , X9-PZC-18, X9-NZ19-21

The one-piece sheet pile protector is also available for the PZ40, PZC18, and NZ 19-21 sheet piles. These protectors are made in the Z configuration for these particular sheets and are made to fit the pair in a left and right section. It opens a slightly larger hole to speed installation and preserve coatings.

Size:
Benefits:  The value of the Protectors has been proven by piles pulled for reuse after being driven. They attach with a minimum of weld and protect pile ends to prevent tearing and buckling of piles.
Steel Grade: Heat-Treated High Strength ASTM A148 90/60.

Download Datasheet

One Piece Sheet Pile Protector

  • Model: SP-PZ-27

The one piece sheet pile protector for the PZ27 sheet pile. These protectors are made in the Z configuration for these particular sheets and are made to fit the pair in a left and right section. It opens a slightly larger hole to speed installation and preserve coatings.

Size: Custom sizes available upon request.
Benefits:  Value of the Protectors has been proven by piles pulled for reuse after being driven. They attach with a minimum of weld and protect pile ends to prevent tearing and buckling of piles.
Steel Grade: Heat-Treated High Strength ASTM A148 90/60.

Download Data Sheet

SKP Sheet Pile Connector

  • Model: SKP

Engineered shapes that provide a full range of corner and junction connections for ball and socket interlock sheet pile. The connector is threaded or welded onto the sheet pile. The SKP is available in several multi-functional designs; SKP90, SKP45, SKPT, SKPF, SKPM.

Size: Custom sizes available upon request.
Benefits: Cost effective and efficient way to transition the orientation of the sheet pile wall as compared to fabrication. SKP connectors are available from stock.
Steel Grade: ASTM A572 Grade 50/60 Domestic or Foreign grade. Special grades upon request.

Download Data Sheet

SKLC-90 Sheet Pile Connector

  • Model: SKLC-90

Engineered shape that provides junction connections for Larssen and most cold form interlock sheet pile. The connector is threaded into the sheet pile.

Size: Custom sizes available upon request.
Benefits: Cost effective and efficient way to transition the orientation of the sheet pile wall as compared to fabrication. SKLC-90 connectors are available from stock.
Steel Grade: ASTM A572 Grade 50/60 Domestic or Foreign grade. Special grades upon request.

Download Data Sheet

E-22 Sheet Pile Connector

Engineered shape that provides a weld on connection for Larssen interlock sheet pile. The connector is welded onto the pile.

Size: Custom sizes available upon request.
Benefits: Cost effective and efficient way to provide a weld on transition for combined wall systems as compared to fabrication. E-22 connectors are available from stock.
Steel Grade: ASTM A572 Grade 50/60 Domestic or Foreign grade. Special grades upon request.

Download Data Sheet

SKAP Sheet Pile Connector

  • Model: SKAP

Engineered shape that provides a transition from a Ball & Socket to Larssen interlock sheet pile. The connector is threaded into the sheet pile.

Size: Custom sizes available upon request.
Benefits: Cost effective and efficient way to transition the orientation of the sheet pile wall as compared to fabrication. SKAP connectors are available from stock.
Steel Grade: ASTM A572 Grade 50/60 Domestic or Foreign grade. Special grades upon request.

Download Data Sheet

Larssen T Sheet Pile Connector

  • Model: Larssen T

Engineered shape that provides a "T" connection for most Larssen interlock piles.

Size: Custom sizes available upon request.
Benefits: Cost effective and efficient way to provide a weld on transition for combined wall systems as compared to fabrication. Larssen T connectors are available from stock.
Steel Grade: ASTM A572 Grade 50/60 Domestic or Foreign grade. Special grades upon request.

Download Data Sheet

Sheet Pile Splicer

  • Model: Z30000

Provides a safe, strong and efficient splice for Z shaped sheet piles. The splicer is a custom splice fabricated for the intended Z shape.

Size: Custom sizes available upon request.
Benefits: Minimum preparation is required on the sheet pile. Nut and bolt assembly allows for quick, easy alignment and weld attachment. Saves time and money versus full penetration welds.
Steel Grade: ASTM A572 Grade 50/60 or special grades

Download General Brochure
